Communication Interface
ADM3065EARMZ-R7
Analog Devices Inc.
RS-485 Transceiver
Key specifications
Up to 50 Mbps
107 mA
3.0 V to 5.5 V
8-Lead MSOP
- Manufacturer
- Analog Devices Inc.
- Package
- 8-Lead MSOP (3 mm x 3 mm)
- Category
- Communication Interface
Genuine, traceable stock
Photographed in our warehouse — factory-sealed with intact labels, lot and date codes.
Datasheet
Full specifications
Basic information
| Manufacturer | Analog Devices Inc. (ADI) |
|---|
8
| Part number | ADM3065EARMZ-R7 |
|---|
11
| Product type | RS-485 Transceiver |
|---|
14
| Communication protocol | RS-485 / PROFIBUS |
|---|
17
| Duplex mode | Half Duplex |
|---|
Performance
| Data Rate | Up to 50 Mbps |
|---|
24
| ESD protection (IEC 61000-4-2) | ±12 kV Contact, ±12 kV Air |
|---|
27
| ESD protection (Human Body Model) | ≥ ±30 kV |
|---|
30
| Bus load | 1/4 Unit Load |
|---|
33
| Receiver hysteresis | 30 mV |
|---|
Power & consumption
| Supply Voltage (VCC) | 3.0 V to 5.5 V |
|---|
40
| Logic supply (VIO) | Not Available (Uses VCC) |
|---|
43
| Operating current | 107 mA |
|---|
46
| Output current | 250 mA |
|---|
Interface characteristics
| Drivers/Receivers | 1 Driver / 1 Receiver |
|---|
53
| Propagation delay | 9 ns |
|---|
56
| Fail-safe | Short-circuit, Open-circuit, Idle-bus |
|---|
59
| Hot-swap support | Yes (Glitch-free power-up/down) |
|---|
Package & environment
| Package | 8-Lead MSOP (3 mm x 3 mm) |
|---|
66
| Mounting type | SMD/SMT (Surface-Mount) |
|---|
69
| Operating temperature | -40°C to +125°C |
|---|
Other features
| Features | Thermal Shutdown, 128 Transceivers on Bus |
|---|
